Next, I drew all of the traces between the components. First, I found and inserted all of the components into the workspace.
When you are ready to fabricate the PCB, its as simple as the click of a button to export your files and upload them directly to Aisler, the partnered fabricator for Fritzing.ĭraw the Schematic I started with the schematic tab to begin the process. I utilized both of these methods for this project. With Fritzing, you can start designing on a virtual breadboard or a schematic, then move to the PCB. There are other great programs like EasyEDA and Eagle available to help design a PCB. This was my first time designing a PCB and this program seemed like the most user friendly and intuitive with the smallest learning curve. To design the PCB I used Fritzing exclusively. There are also a few PDFs that I found helpful. Simon Inns has a great and more in-depth write up about the theory.
#4 bit checksum calculator full#
The schematic for the Full Adder is above. In my project I cascaded 4 Full Adders which enabled me to have 4 bit inputs. Full Adders can then be cascaded together to add larger binary numbers. This is accomplished by combining 2 Half Adder circuits to generate a Full Adder.
In order to add larger binary numbers, the carry bit must be incorporated as an input. This is known as a Half Adder and the schematic is shown above. Thus, using both an XOR with an AND gate can represent the whole table. The carry bit results can be represented by a simple AND gate. If both inputs are 1 the resulting output is 0. The input has to be exactly 1 to result in an output of 1. This combination of logic is also known as an exclusive OR (XOR) gate. Referring back to the table, A combination of these gates can be used to produce the Sum results in the table. They are made up of different combinations and wiring of transistors and resistors. Some of the most basic logic gates consist of the NOT, AND, and OR gates which are all utilized in this project. Logic gates take inputs and generate an output. When adding two bits (A and B) together, 4 different results are possible with the outputs of Sum and Carry (Cout). An example of counting in base 2:ġ+1 = 0 and you carry the 1 to the next bit A combination of 1's and 0's are used to represent different integers and their sums. The simplest example:Ĭounting in base 2 or binary only uses 1's and 0's. Much of the inspiration and understanding of this project came from Simon Inns.Ĭounting in base 10 is simple because there is a different integer to represent the sum of two integers.
#4 bit checksum calculator how to#
My goals for this project included: 1) Learn how to create and fabricate a custom PCB 2) Make the design easy to conceptualize adding binary numbers 3) Demonstrate the difference in scale between discrete components and an integrated circuit performing the same task The purpose of this project was to utilize these discrete components to learn and create my own 4-bit adder calculator. In the videos, logic gates were created out of dominos but they can also be made out of basic components, namely transistors and resistors. Building an entire personal computer out of dominos is absurd but I still wanted to understand the use of discrete components to accomplish this adding task.
Matt Parker extends this basic concept and builds a Domino Computer circuit using 10,000 dominos. This video by numberphile does an excellent job of explaining this concept via Domino Addition. One of the simplest operations performed is adding two numbers together, in an adder circuit. To accomplish this task, computers utilize binary numbers and logic gates. One important fundamental component in a CPU is the arithmetic logic unit or the ALU which performs operations on integer numbers. I wanted to understand the use of discrete components and the circuits necessary to accomplish more complex tasks. I developed an interest in the way computers work on a fundamental level.
